Product overview
Senville AURA 36,000 BTU 23 SEER2 Ceiling Cassette 2 Zone Ductless Mini Split - Energy Star - 230V (18K + 18K)
This 36,000 BTU 23 SEER2 Dual Zone Ceiling Cassette Air Conditioner by Senville is one of the most advanced and high-end split units on the market. Providing you with a variety of features including, SEER2 23, two 18,000 BTU Air Handlers, Air Conditioner & Heat Pump, Turbo Mode, Dehumidification, Timer Function, Follow Me Function and much more. Ideal for spaces 1,350 to 1,800 sq. ft.
Features:
- 23 SEER2
- With Heat Pump (Up to -30C / -22F)
- Energy Star Certified
- Whisper Technology (Ultra Quiet)
- Refrigerant Leak Detection
- Inverter Technology
- Vertical Swing Function
- Built-In De-humidification Function
- Follow Me Function (Remote with Built-In Thermostat)
- Low Ambient Cooling (Up to -30C / -22F)
- Self-Cleaning Mode
- PTC Heat Belt and Pan
- Bucket Free Outdoor Design
- Self Diagnosis System
Specifications:
| Electrical Requirements | |
|---|---|
| Voltage | 208/230V |
| Phase | 1 |
| Cycle | 60 Hz |
| Minimum Circuit (Disconnect) | 37 A |
| Maximum Fuse (Breaker) | 40 A |
| Condenser (36,000 BTU) | |
| Number of Zones | 2 |
| Dimensions | 38.58" W x 16.14" D x 38.39" H |
| Weight | 211.86 lbs |
| Cooling Capacity | 36,000 BTU |
| Outdoor Operating Temperature (Cooling) | -22°F - 122°F |
| SEER2 | 23 |
| EER2 | 13 |
| Heating Capacity | 36,000 BTU |
| Outdoor Operating Temperature (Heating) | -22°F - 86°F |
| HSPF2-4 | 10.7 |
| HSPF2-5 | 8.5 |
| COP W/W | 4 |
| Outdoor Noise Level | 65 dB |
| Outdoor Air Flow (Max) | 3037.2 CFM |
| Air Handler (18,000 BTU) | |
| Dimensions | 22.44" W x 22.44" D x 9.65" H |
| Coverage Area | 550 to 1,000 sq ft. |
| Cooling Capacity | 18,000 BTU |
| Heating Capacity | 18,000 BTU |
| Refrigerant & Piping | |
| Refrigerant Type | R454B |
| Refrigerant Volume | 134.04 oz |
| Certifications & Warranty | |
| Certifications | Energy Star Certified, UL Certified |
| Warranty | 10 Years Compressor / 5 Years Parts |
In-stock systems ship fast and free with curbside freight delivery, typically arriving in 4–10 days. Please inspect each box at delivery and note any damage on the receipt before signing — it keeps any freight claim quick and simple.
Ask AI
Ask AI about this product
Ask our AI product assistant about sizing, compatibility, electrical needs, accessories, shipping, warranty, and install planning.
At a glance
Tech specs
| Condenser capacity | 36,000 |
|---|---|
| Indoor unit(s) | 18K + 18K |
| Coverage area | 1,550 Sq Ft. |
| Zones / rooms | 2 Zones |
| Efficiency | 23 SEER2 |
| Power | 230 Volt |
| Line set | Custom |
| Mount type | Ceiling |
| Installation | Professional Installation |
| Brand | Senville |
Sizing in doubt? Our HVAC experts confirm capacity for your rooms before you order — free. Ask us about utility rebates for high-efficiency heat pumps in your area.
