MRCOOL VersaPro 5 Ton Horizontal Package Heat Pump - R-454B
The MRCOOL® VersaPro® Series 60K Package Heat Pump is built to deliver reliable, year-round comfort through a compact, all-in-one system. Built for maximum performance in all seasons, it’s an excellent choice for large homes or demanding applications requiring year-round reliability. With a 13.4 SEER2 efficiency rating, the VersaPro® 60K helps reduce energy consumption, lowering monthly utility costs while minimizing environmental impact. It uses R-454B refrigerant, a next-generation solution with a much lower global warming potential than older refrigerants, supporting eco-conscious upgrades without sacrificing performance. Designed for durability, the system features a power-painted galvanized steel cabinet for protection against harsh weather and corrosion. Its horizontal discharge design ensures quiet operation, while aluminum tubing and fin coils improve heat transfer and resist corrosion better than copper—extending service life and reducing long-term maintenance needs.
Backed by a 10-year limited parts warranty and 10-year compressor warranty following registration, the MRCOOL® VersaPro® 60K Package Heat Pump is a dependable investment in year-round comfort, energy savings, and peace of mind.
Key Features:
- Quiet Horizontal Discharge
- Durable Galvanized Steel Cabinet
- High Efficiency Compressor
- Internal Safeguards
- Copper Tube/Aluminum Fin Coil
- Optional Electric Heat Kit
Install Manuals and Guides:
VersaPro Packaged Unit Brochure
VersaPro Packaged Unit Install Manual
VersaPro Packaged Unit Warranty Information
Specifications:
| BRAND NAME | MRCOOL |
| SERIES |
VersaPro® R-454B Package Heat Pump
|
| MODEL | MPH601HO13C |
| GTIN | 840255588706 |
| UPC | 840255588706 |
| UNIT TYPE | Packaged Heat Pump |
| SHORT DESCRIPTION |
5 Ton Horizontal VersaPro® Package Heat Pump - R454B
|
| SEER2 | 13.4 |
| EER2 | 11 |
| HSPF2-4 | 6.7 |
| CFM | 1750 |
| TONNAGE | 5 |
| COOLING CAPACITY (BTU) | 56,500 |
| HEATING CAPACITY (BTU) | 56,000 |
| VOLTAGE (V) | 208/230 |
| PHASE | 1 |
| CYCLE | 60 |
| MAX FUSE BREAKER (A) | 60 |
| MIN CIRCUIT AMPACITY (A) | 48.6 |
| COLOR | Grey |
| RATED LOAD | 32 |
| FULL LOAD | 125 |
| REFRIGERANT TYPE | R-454B |
| REFRIGERANT VOLUME (OZ) | 95 |
| DECIBEL RATING (DBA) | 81 |
| INVERTER | No |
| MIN AMBIENT COOL (F) | 32 |
| MIN AMBIENT HEAT (F) | -0.4 |
| DRAIN CONNECTION SIZE | 3/4 |
| CONTROL TYPE | 24V Thermostat |
| COMPRESSOR MOTOR TYPE | Scroll |
| CONDENSER FAN MOTOR TYPE | ECM |
| CONDENSER FAN MOTOR HP | 1/4 |
| BLOWER MOTOR TYPE | ECM |
| BLOWER MOTOR HP | 3/4 |
| BLOWER MOTOR SPEEDS | 3 |
| METERING DEVICE | Piston |
| AUXILIARY HEATER INCLUDED | No |
| AUXILIARY HEATER AVAILABLE | Yes |
| AUXILIARY HEATER SIZES |
5 KW / 7.5 KW / 10 KW / 15 KW / 20 KW
|
| UL LISTED | Yes |
| CSA LISTED | Yes |
| ETL LISTED | Yes |
| AHRI CERTIFIED | Yes |
| REGISTERED WARRANTY | 10 Year Parts, 10 Year Compressor |
| BASE WARRANTY | 5 Year Parts, 5 Year Compressor |
| REGISTERED PARTS WARRANTY | 10 Year Parts |
| BASE PARTS WARRANTY | 5 Year Parts |
| REGISTERED COMPRESSOR WARRANTY | 10 Year Compressor |
| BASE COMPRESSOR WARRANTY | 5 Year Compressor |
| CONTAINS ELECTRONICS | Yes |
| CONTAINS CHEMICALS | Yes |
| CONTAINS COMPRESSED GAS | Yes |
| PROPOSITION 65 WARNING | Yes |
| NET DEPTH (IN) | 58.5 |
| NET HEIGHT (IN) | 33.06 |
| NET WIDTH (IN) | 42.06 |
| NET WEIGHT (LBS) | 450 |
| GROSS DEPTH (IN) | 59.25 |
| GROSS HEIGHT (IN) | 34.07 |
| GROSS WIDTH (IN) | 42.24 |
| GROSS WEIGHT (LBS) | 467 |
In-stock systems ship fast and free with curbside freight delivery, typically arriving in 4–10 days. Please inspect each box at delivery and note any damage on the receipt before signing — it keeps any freight claim quick and simple.
